ELECTRONIC Mono-Stabil MAGNETIC SWITCH
| Product code | : | MMS |
| Supply | : | 10-30Vdc / 9-20Vac 50/60Hz |
| Output types | : | MMS-P : positive switching (+ out) |
| MMS-N : negative switching (- out) | ||
| Sensing distance | : | 5-25mm |
| Output current | : | 300mA (maks.) |
| Indicators | : | Output activated (with yellow LEDs) |
| Output overcurrent/short circuit (with red LED) | ||
| Dimensions | : | Ø20x95(mm) |
| Protection class | : | IP65 |
| Fixing | : | M20 Standard |
| Connection | : | 1.000mm TTR cable |
|
||
